allPIXA evo 8k DXGE Mono TDI X

Lens mount : M72 x 0.75

The allPIXA evo 8K mono camera offers CMOS performance with CCD image quality. The novel multi-line CMOS mono sensor enables TDI options at full speed. Line rates up to 100 kHz are possible with the fast and cost-efficient 10 GigE interface. For easy integration, Chromasens provides an intuitive GUI and an SDK for camera control and high-speed image capture for Windows and Linux.

Features

• Tri- or quadlinear CMOS line sensor
• 8,192 x 4 pixels
• Pixel size 5 x 5 µm
• Interfaces 10GigE (SFP+)
• Line rates up to 100 kHz
• Output up to 4x 8/10/12 bit
• Mono mode
• Frame and line trigger options including an intelligent and flexibly adjustable encoder input
• Cable lengths up to 100 m with 10GigE (SFP+)
• SDK and graphical tool for setting camera parameters and image acquisition for Windows and Linux

Applications

• High-speed print inspection
• PCB & AOI
• Wafer inspection
• Sorting processes
• High-resolution surface inspection
• Food
• Semiconductor
• EV battery
