The A9507CX703E is equipped with a 10GigE high-speed transmission interface, enabling real-time delivery of high-resolution images, making it ideal for precision inspection and high-speed computing applications.
| A9507CX703E | |
| Sensor | GMAX2505 |
| Image Sensor | 6.5 mm × 5.4 mm CMOS |
| Shutter | Global |
| Resolution | 2592 × 2160 |
| Frame Rate | 210 fps |
| Bit Depth | 10 bit |
| Mono/Color | Color |
| Pixel Size | 2.5 μm × 2.5 μm |
| Pixel | 5 MP |
| S/N Ratio | 36.9 dB |
| Dynamic Range | 62 dB |
| Image Format | BayerGB8/BayerGB10 |
| ROI | Support |
| X Flip | Support |
| Y Flip | Support |
| Gain | Analog gain: 1× ~ 2×, Digital gain: 1× ~ 100× |
| Exposure Time | 2 μs ~ 5 s |
| Trigger Mode | Software Trigger/Hardware Trigger/Free Run Mode |
| SPC | Support |
| User Setting | Support two sets of user-defined configurations |
| Port | CXP-6 |
| GPIO Interface | 1× Opto-isolated input, 1× Opto-isolated output, 1× configurable input and output |
| Lens Mount | C-mount |
| Power Supply | DC 24V power supply via 6 Hirose interface，support PoCXP |
| Power Consumption | 24 V ≈ 6.4 W |
| Product Dimensions | 50 mm × 50 mm × 44.7 mm (Non including rear case connector) |
| Net Weight | 240 g |
| Storage Temperature | -30℃ ~ 80℃ |
| Operating Temperature | -30℃ ～ 50℃ |
